JinkoSolar - Inverter Reviews

About JinkoSolar

While best known for its solar panels, China's JinkoSolar also has a home battery and compatible hybrid inverter in its lineup of products available in Australia.

Australian Office Contact Information

Address: 2A 152 Marsden Street, Parramatta NSW 2150
Phone: 1300 326 182
Email: [email protected]
Australian Website

Company Info

JinkoSolar was founded in 2006, but it wasn't until much later that the firm expanded into energy storage - originally commercial & industrial and utility scale solutions. In 2022, Jinko launched its first home battery system, the Suntank, in Australia.

JinkoSolar Suntank Hybrid Inverter

The JKS-5HLVS-ABI series is for use with Jinko's Suntank battery modules (JKS-B51X-BI). Available in 3kW, 3.6kW, 4kW, 4.6kw, 5kW and 6kW versions with efficiencies up to 97.6%, this single-phase hybrid inverter offers up to 4kW output (depending on the model) in backup scenarios, with a switchover time of <16ms.

Naturally (convection) cooled, the The JKS-5HLVS-ABI measures 456 x 565 x 188mm, weighs 27 kg and has an operating temperature range of -25? ~ +60?. IP65 rated, it can be installed outdoors, but it's always wise to locate an inverter where it won't be in direct sunlight.

More specifications can be found on SQ's hybrid inverter comparison table.

It's worth noting Jinko doesn't manufacture its hybrid inverters. While it's not clear who the manufacturer is, they look very similar to a Growatt hybrid inverter.

Warranty Information

The warranty for the JKS-5HLVS-ABI is ten years - but that assumes it remains connected to the internet through Jinko's monitoring system.  The warranty is halved to five years if it is not connected. Note that the installation manual says it should be installed under shelter, out of direct rain and direct sunlight.
