Diehl solar inverters reviews
Based on 1 rating Aus Ranking
- 5 star 1
- 4 star 0
- 3 star 0
- 2 star 0
- 1 star 0
The views expressed by reviewers are theirs alone, and do not necessarily reflect those of SolarQuotes Home Electrification Pty Ltd, which makes no representations as to the accuracy of the reviews. For our full disclaimer and further information, see our Terms of Use and our Review Guidelines.
Diehl Stiftung & Co. KG is a family-owned German company established in 1902 and based in Germany (Nürnberg).The Diehl Group incorporates five divisions: Diehl Metering, Diehl Aerosystems, Diehl Defence, Diehl Metall, and Diehl Controls, plus several joint ventures and 40 subsidiaries.
In the photovoltaic industry, since 2004, the company has been producing solar inverters and other solar-related products using the name Platinum. The company became an autonomous brand in 2013, but all inverters are still produced by Diehl Controls in Allgäu.
Diehl’s range of solar products consists of string inverters and single and three-phase inverters with an energy output from 2 to 22 kW. Diehl also supplies several other PV solutions suitable for outdoor applications and for any kind of residential and commercial project.
Diehl is a company able to serve its customers globally thanks to several commercial branches located in Germany, Poland, Mexico, North America and China. However, the company does not have any Australian office yet, so should you have any specific enquiry or request, you should contact their German headquarters first.
If you want to learn more about Diehl’s range of photovoltaic products, simply check out the products listed below to find the ones that best match your needs and requirements.
Diehl Solar Inverter Reviews
Bought From: Propa Solutions Pty ltd Show additional information
Diehl has 45 solar inverters in our database
Model | DC Voltage | AC Power | Efficiency |
---|---|---|---|
11000 R3-MDX | 690 V-900 V | 10 kW | 98.40 |
13000TLD | 350-880 | 12360 | 97.70 |
14000 R3-MDX | 900 V | 13,000 W | 98.40 |
16000 R3-MDX | 900 V | 15,000 W | 98.40 |
16000TLD | 350-880 | 15000 | 97.70 |
19000TLD | 350-880 | 18000 | 98.00 |
2100 H | 220 - 600 | 2000 | 94.70 |
2100S | 206-390 | 1900 | 94.70 |
22000TLD | 350-880 | 20700 | 98.00 |
22001TLD | 350-880 | 20000 | 98.00 |
2800S | 313-630 | 2600 | 95.30 |
3000 H | 220 - 600 | 2900 | 97.00 |
3100S | 314-630 | 2800 | 95.30 |
3800 TLD | 340-710 | 3680 | 340.00 |
3800S | 315-630 | 3600 | 95.60 |
3801 TLD | 340-880 | 3330 | 97.70 |
4000 H | 220 - 600 | 3800 | 96.60 |
4300 TLD | 340-880 | 4120 | 97.70 |
4300S | 320-630 | 4050 | 95.60 |
4301S | 277-470 | 4050 | 94.60 |
4600 H | 220 - 600 | 4400 | 95.60 |
4600S | 320-630 | 4200 | 95.60 |
4601S | 278-470 | 4200 | 94.60 |
4800 TLD | 340-880 | 4600 | 97.70 |
5300 TLD | 340-880 | 5000 | 97.70 |
6300 TLD | 340-880 | 6000 | 98.00 |
7000 R3-MDX | 350-720 | 6.000 W | 98.00 |
7200 TLD | 710V | 6900 | 98.00 |
9000 R3-MDX | 350-720 | 8.000 W | 98.00 |
Platinum 13000TL | 350-710 | 12360 | 97.30 |
Platinum 16000TL | 350-710 | 15000 | 97.40 |
Platinum 19000TL | 350-710 | 18000 | 97.00 |
Platinum 22000TL | 350-880 | 20700 | 98.00 |
PLATINUM 3800TLD | 340-710 | 3680 | 97.40 |
PLATINUM 3801TLD | 340-710 | 3330 | 97.70 |
Platinum 4300TL | 340-710 | 4120 | 97.70 |
PLATINUM 4300TLD | 340-710 | 4120 | 97.00 |
Platinum 4800TL | 340-710 | 4600 | 97.40 |
PLATINUM 4800TLD | 340-710 | 4600 | 97.70 |
Platinum 5300TL | 340-710 | 4600 | 97.40 |
PLATINUM 5300TLD | 340-710 | 5000 | 97.70 |
Platinum 6300TL | 340-710 | 6000 | 97.70 |
PLATINUM 6300TLD | 340-710 | 6000 | 98.00 |
Platinum 7200TL | 340-710 | 6900 | 98.00 |
PLATINUM 7200TLD | 340-710 | 6900 | 98.00 |
